JI TF Wall 1100 80-100 (Smooth)

Wall Panels

JI TF Wall 1100 80-100 (Smooth) is an insulated panel with through-fixings. This cladding panel can be installed both vertically and horizontally. The sandwich panel consists of a smooth outer steel sheet, a core of polyisocyanurate (PIR) foam without harmful CFC-HCFC compounds, and a lightly profiled inner steel sheet. Additionally, the panels have a fire resistance rating of EI30. These walls are perfectly suitable for projects with high thermal requirements in agricultural, industrial, and commercial sectors, such as cooling and refrigeration applications.

FM/LPCB needed : contact your local sales representative

JI TF Wall 1100 80-100 (Smooth)

Specifikationer JI TF Wall 1100 80-100 (Smooth)

Lösningar

Mått

Längd:
Min. 2500,0mm/ max. 13600,0mm
Bredd:
Max. 1100,0mm

Tjocklek och vikt

80 mm:
11,83 kg/m²
100 mm:
12,62 kg/m²
JI TF Wall 1100 80-100 (Smooth)

Egenskaper

Material:
Steel S280 GD

Referensstandarder

Galvaniserat stål:
EN 10346:2015 - tolerances according to EN 10143:2006
Bandlackering:
EN 10169:2022
Tolerans:
EN 14509:2013 (Geometry)
Beräkningar:
EN 14509:2013

Isolering

Kärna:
Polyisocyanurate (PIR)

Isoleringstabell

Isoleringstabell – tjocklek (mm) U (W/m²K) R (m².K/W) Ei (minutes)
80,0 0,26 3,75 - - -
100,0 0,21 4,7 30,0 (i<->o) hor / vert
